Post diameter |
30.9mm, 31.6mm, 34.9mm |
Travel |
100mm, 125mm, 150mm, 175mm, 200mm, 225mm, 250mm |
Post length |
348.2mm, 352.8mm, 398.2mm, 402.8mm, 448.2mm, 452.8mm, 498.2mm, 502.8mm, 548.2mm, 552.8mm, 598.2mm, 602.8mm, 648.2mm, 652.8mm |
Remote |
AXS Controller Sold Separately |
Saddle Rail Compatibility |
Round/Oval (7x9 & 7x10) |
E-Bike Approved |
E-bike Approved |
Minimum Frame Insertion |
110mm, 120mm, 160mm, 80mm |
Maximum Frame Insertion |
185.7mm, 188.6mm, 210.7mm, 213.6mm, 235.7mm, 238.6mm, 260.7mm, 263.6mm, 285.7mm, 288.6mm, 310.7mm, 313.6mm, 335.7mm, 338.6mm |
Minimum Exposed Height |
162.5mm, 164.2mm, 187.5mm, 189.2mm, 212.5mm, 214.2mm, 237.5mm, 239.2mm, 262.5mm, 264.2mm, 287.5mm, 289.2mm, 312.5mm, 314.2mm |
Maximum Exposed Height |
268.2mm, 272.8mm, 318.2mm, 322.8mm, 368.2mm, 372.8mm, 418.2mm, 422.8mm, 438.2mm, 442.8mm, 478.2mm, 482.8mm, 488.2mm, 492.8mm |
Weight (g) |
712 |
Weight Based On |
200mm 31.6 W/O battery - Battery 25g |
